TP-LINK ARCHER T4U AC1300 Wireless Dual Band USB 3.0 Adapter

HARDWARE FEATURES

INTERFACE

USB 3.0

BUTTON

WPS button

DIMENSIONS ( W X D X H )

3.64×1.24×0.55 in. (92.47×31.55×13.9mm)

ANTENNA

2 High Gain External Antennas

ANTENNA TYPE

Omni Directional

WIRELESS FEATURES

WIRELESS STANDARDS

IEEE 802.11ac, IEEE 802.11a,

 IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

FREQUENCY

5GHz

 2.4GHz

SIGNAL RATE

5GHz

 11ac: Up to 867Mbps(dynamic)

 11n: Up to 300Mbps(dynamic)

 11a: Up to 54Mbps(dynamic)

 2.4GHz

 11n: Up to 400Mbps(dynamic)

 11g: Up to 54Mbps(dynamic)

 11b: Up to 11Mbps(dynamic)

RECEPTION SENSITIVITY

5GHz：

 11a 6Mbps: -91dBm

 11a 54Mbps: -77dBm

 11nHT20：-74dBm

 11nHT40：-71dBm

 11ac HT20: -70dBm

 11ac HT40: -66dBm

 11ac HT80: -62dBm

 2.4GHz:

 11b 11Mbps: -86dBm

 11g 54Mbps: -74dBm

 11n HT20: -72dBm

 11n HT40: -70dBm

TRANSMIT POWER

<20dBm (EIRP)

WIRELESS MODES

Ad-Hoc / Infrastructure mode

WIRELESS SECURITY

Support 64/128 bit WEP, WPA-PSK/WPA2-PSK

MODULATION TECHNOLOGY

DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

OTHERS

CERTIFICATION

CE, FCC, RoHS

PACKAGE CONTENTS

AC1300 High Gain Wireless MU-MIMO USB Adapter Archer T4U

 Quick Installation Guide

 Resource CD

SYSTEM REQUIREMENTS

Windows 10/8.1/8/7/XP, Mac OS X 10.9-10.13

ENVIRONMENT

Operating Temperature: 0℃~40℃  (32℉~104℉)

 Storage Temperature: -40℃~70℃  (-40℉~158℉)

 Operating Humidity: 10%~90% non-condensing

 Storage Humidity: 5%~90% non-condensing
